Product Introduction:
The new LHS boiler is a vertical industrial boiler, and the combustion equipment is a movable grate. The working medium circulates naturally. The flue gas flushes the inner wall of the furnace and the water pipe in the furnace, and performs radiation and convection heat exchange. The water-cooled grate pipe in the furnace and the lower part of the furnace are the radiation heating surface, and the water pipe and the upper part of the furnace are the convection heating surface. After the external installation of the boiler is completed, it is insulated on site.
Product Advantages:
2) The horizontal water pipe is adopted to eliminate the disadvantage of ash accumulation in the smoke tube of the fire tube boiler.
(3) The structure is compact. Compared with the same type of boilers, the external dimensions are small, which saves the investment in the infrastructure of the boiler room. The boiler heats up and has the characteristics of improving the thermal efficiency of the passage.
(4) Stable operation, convenient adjustment and sufficient output.
Technical Parameters:
| Model | Rated Capacity (t/h) | Rated Pressure (Mpa) | Rated Temperature (C) | Maximum transport weight of boiler(t) | Maximum transport size of boiler( mm) | Fuel Consumption |
| diesel oil (Kg/h) | Natural gas (m³/h) | LPG (kg/h) |
| LHS0.05 | 0.05 | 0.4 | 151 | 0.37 | 700× 650×1700 | 8.2 | 10.2 | 6.45 |
| LHS0.1 | 0.1 | 0.59 | 800×750 ×2000 | 11.3 | 13.6 | 13 |
| LHS0.2 | 0.2 | 0.4~0.7 | 151~170 | 0.68 | 900× 850×2000 | 15.6 | 18.7 | 19.4 |
| LHS0.3 | 0.3 | 0.83 | 1000×950×2000 | 22.5 | 26.8 | 25.6 |
| LHS0.5 | 0.5 | 1.07 | 1100×1050×2000 | 32.5 | 36.8 | 32 |
| LHS0.7 | 0.7 | 0.4~0.7 | 151~170 | 1.45 | 1200×1150×2200 | 40.6 | 48.5 | 50 |
| LHS1 | 1 | 1.78 | 1300×1250×2450 | 45.9 | 65.3 | 65 |
| LHS1.5 | 1.5 | 1.9 | 1780×1600×3200 | 78.4 | 102.1 | 97 |
| LHS2 | 2 | 5.2 | 2000×2000×4000 | 91.8 | 130.6 | 130 |
| | Note: 1,Fuel type:Light diesel oil/Heavy oil/Natural gas/Liquefied gas/City gas 2 ,Parameter is for reference only, we can design the boilers based on customers’ needs. |
FAQ
Q1: How can you get the best price quickly?
1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.
Q2:Why choose us?
1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.
Q3: Details of electric control cabinet
Electric control cabinet adopts PLC touch screen, display in English. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc. In addition, the cabinet is used for set up the parameter, record and analyze the operation data, etc.
Q4:What is the using life of your boiler?
1.Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,the boiler can be used for 20-25 years.
