Manufacturer'S Direct Selling Industrial Steam Generator Vertical Steam Generator Price

Name: ManufacturerS Direct Selling Industrial Steam Generator Vertical Steam Generator Price
Brand: TAIGUO
Price: 1 USD

Manufacturer'S Direct Selling Industrial Steam Generator Vertical Steam Generator Price Manufactures

Brand Name : TAIGUO

Model Number : LHS

Certification : CE、EAC、SGS

Place of Origin : Henan, China

MOQ : 1

Price : US $6000.00

Payment Terms : L/C, T/T, D/P, T/T

Supply Ability : 100set

Delivery Time : 25 working days

Packaging Details : Bulk, packaged

Product name : Vertical steam boiler

Steam yield : 0.1t/h-1t/h

Fuel : Oil/Gas-fired

Structural form : Vertical type

Steam Production : 50Kg ~ 2000Kg / h

Key Selling Points : Automatic

Type : Once Through

Pressure : Low Pressure

Dimension(L*W*H) : Depend on requirments

Material : q245r

Combustion method : Automatic Burner

Working pressure : 0.4 / 0.7Mpa

Thermal efficiency : 98%

Color : Customer's Requirement

Contact Now

Product introduction:

The steam generator model is LHS, which is an oil and gas three way internal combustion steam generator equipped with a flue gas recovery energy-saving device, which can meet environmental protection requirements and improve boiler thermal efficiency. Compliant with national energy-saving and environmental protection requirements, with a fire pipe layout structure, fast installation throughout the factory, simple operation, convenient maintenance, safety, stability and reliability, low operating costs, it is a generation of environmentally friendly and efficient energy-saving products.

Product advantage:

1. Complete combustion waste heat recovery high thermal efficiency
2. One-click operation is safe and convenient
3. Multi-protection security guarantee
4. Strictly test industry standards

Product technical parameters:

Model

Rated

Capacity

(t/h)

Rated

Pressure

(Mpa)

Rated

Temperature

(C)

Maximum

transport weight

of boiler(t)

Maximum transport size of boiler( mm)

Fuel Consumption

diesel oil (Kg/h)

Natural

gas (m³/h)

LPG (kg/h)

LHS0.05

0.05

0.4

151

0.37

700× 650×1700

8.2

10.2

6.45

LHS0.1

0.1

0.59

800×750 ×2000

11.3

13.6

LHS0.2

0.2

0.4~0.7

151~170

0.68

900× 850×2000

15.6

18.7

19.4

LHS0.3

0.3

0.83

1000×950×2000

22.5

26.8

25.6

LHS0.5

0.5

1.07

1100×1050×2000

32.5

36.8

LHS0.7

0.7

0.4~0.7

151~170

1.45

1200×1150×2200

40.6

48.5

LHS1

1.78

1300×1250×2450

45.9

65.3

LHS1.5

1.5

1.9

1780×1600×3200

78.4

102.1

LHS2

5.2

2000×2000×4000

91.8

130.6

130

Note: 1,Fuel type:Light diesel oil/Heavy oil/Natural gas/Liquefied gas/City gas

2 ,Parameter is for reference only, we can design the boilers based on customers’ needs.
