Steam Generator Boiler Small Vertical Steam Boilers Generator Machine

Product Categories
HENAN TAIGUO BOILER PRODUCTS CO.,LTD.
Contact Now

Steam Generator Boiler Small Vertical Steam Boilers Generator Machine

  • 1
  • 2

Brand Name : TAIGUO

Model Number : LHS

Certification : CE、EAC、SGS

Place of Origin : Henan, China

MOQ : 1

Price : US $5500.00

Payment Terms : L/C, T/T, D/A, T/T

Supply Ability : 100set

Delivery Time : 22 working days

Packaging Details : Bulk, packaged

Product name : Vertical steam boiler

Steam capacity : 0.1t/h-1t/h

Working pressure : 0.7Mpa

Structural form : Vertical type

Warranty of core components : 1 Year

Core Components : boiler body

Key Selling Points : high efficiency

Condition : New

Type : Natural Circulation

Structure : Fire Tube

Style : VERTICAL

Dimension(L*W*H) : customized

Burner brand : riello,baltur,hofamat,oilon

Thermal efficiency : >93%

Voltage : 220-460V/50-60Hz

Contact Now

Product introduction:

The TAIGUO vertical steam boiler operating system is fully automatic touch screen control, and all operating conditions can be clearly seen on the LCD screen. You can observe the working status, water level status, steam pressure high and low status, pump operation status, fault alarm status, etc. on the display screen, so that you can always grasp the operating status of the equipment and use it with peace of mind.
The use of high-quality components: All pipelines and instruments are connected with seamless steel pipes or pressure resistant copper pipes, and the electrical appliances are well-known in China, ensuring safe and reliable use.

Product advantages:

1. Environmental protection
Widely applicable and in compliance with environmental requirements;
2. Economy
By adopting the latest energy-saving and environmental protection technologies, it can save about 3-8% of costs per month. Using efficient insulation materials, the heat loss is very low, saving fuel costs;
3. Safety
Equipped with water shortage, overpressure, and overheating protection functions, safe and reliable;
4. Practicality
The device has a simple structure, a small footprint, convenient installation and maintenance, and a long service life.

Technical parameter:

Model

Rated

Capacity

(t/h)

Rated

Pressure

(Mpa)

Rated

Temperature

(C)

Maximum

transport weight

of boiler(t)

Maximum transport size of boiler( mm)

 Fuel Consumption

diesel oil (Kg/h)

Natural

gas (m³/h)

LPG (kg/h)
LHS0.05 0.05

0.4

151

 0.37 700× 650×1700 8.2 10.2 6.45
LHS0.1 0.1 0.59 800×750 ×2000 11.3 13.6 13
LHS0.2 0.2

0.4~0.7

151~170

 0.68 900× 850×2000 15.6 18.7 19.4
LHS0.3 0.3 0.83 1000×950×2000 22.5 26.8 25.6

LHS0.5

0.5

1.07

1100×1050×2000

32.5

36.8

32

LHS0.7

0.7

0.4~0.7

151~170

1.45

1200×1150×2200

40.6

48.5

50

LHS1

1

1.78

1300×1250×2450

45.9

65.3

65

LHS1.5

 1.5

1.9

1780×1600×3200

78.4

102.1

97

LHS2

2

5.2

2000×2000×4000

91.8

130.6

130

Note: 1,Fuel type:Light diesel oil/Heavy oil/Natural gas/Liquefied gas/City gas

2 ,Parameter is for reference only, we can design the boilers based on customers’ needs.
