Automatic Gas Oil Fired LPG Steam Boiler Powered Steam Generator High Efficiency

Name: Automatic Gas Oil Fired LPG Steam Boiler Powered Steam Generator High Efficiency
Brand: TAIGUO
Price: 9000 USD

Automatic Gas Oil Fired LPG Steam Boiler Powered Steam Generator High Efficiency Manufactures

Brand Name : TAIGUO

Model Number : LHS

Certification : CE、EAC、SGS

Place of Origin : Henan, China

MOQ : 1

Price : USD9000-22500 set

Payment Terms : L/C, T/T, D/A, D/P

Supply Ability : 100set

Delivery Time : 15-25DAYS

Packaging Details : Bulk, packaged

Product name : industrial steam boilers

Steam yield : 0.1t/h-4t/h

Working pressure : 1.3-1.5 MPa

Key Selling Points : Quick Steam Generation

Type : Natural Circulation

Structure : Once Through

Style : VERTICAL

Fuel : Gas-Fired

Steam Temperature : 151/170 ℃

Thermal efficiency : 98%

Contact Now

High Efficiency Automatic Gas Fired Oil Fired LPG Steam Boiler Powered Steam Generator
LSS oil/gas fired series fast steam generator is a kind of small vertical automatic heating equipment. It can generate steam quickly (about 3 ~ 5 minutes) and has high thermal efficiency. It has a vertical pipe structure, small water volume, safety and no need of annual inspection. The whole set of equipment can generate steam only by connecting water source and power supply.

Product advantage:

1. Practicality
The steam generator has the advantages of simple structure, small footprint, convenient installation and maintenance, and long service life.
2. Convenience
Can choose automatic computer type and digital display type two kinds of control, easy to operate, less fault, easy to use;
3. Adjustability
The load can be adjusted arbitrarily within the rated range as required;

Technical parameter:

Model

Rated

Capacity

(t/h)

Rated

Pressure

(Mpa)

Rated

Temperature

(C)

Maximum

transport weight

of boiler(t)

Maximum transport size of boiler( mm)

Fuel Consumption

diesel oil (Kg/h)

Natural

gas (m³/h)

LPG (kg/h)

LHS0.05

0.05

0.4

151

0.37

700× 650×1700

8.2

10.2

6.45

LHS0.1

0.1

0.59

800×750 ×2000

11.3

13.6

LHS0.2

0.2

0.4~0.7

151~170

0.68

900× 850×2000

15.6

18.7

19.4

LHS0.3

0.3

0.83

1000×950×2000

22.5

26.8

25.6

LHS0.5

0.5

1.07

1100×1050×2000

32.5

36.8

LHS0.7

0.7

0.4~0.7

151~170

1.45

1200×1150×2200

40.6

48.5

LHS1

1.78

1300×1250×2450

45.9

65.3

LHS1.5

1.5

1.9

1780×1600×3200

78.4

102.1

LHS2

5.2

2000×2000×4000

91.8

130.6

130

Note: 1,Fuel type:Light diesel oil/Heavy oil/Natural gas/Liquefied gas/City gas

2 ,Parameter is for reference only, we can design the boilers based on customers’ needs.
