Fully Automatic 100kg 200kg 500kg Vertical Natural Gas Diesel Oil Steam Generator
Product Description:
The structure of the LHS type oil and gas steam generator consists of a layer of water surrounding the combustion chamber. This reduces heat loss, saves energy, and lowers operating costs.
The casing and fire hoses are made of special materials that meet the thickness requirements of European and American standards. These materials have high strength, reliable performance, safety and stability, and long service life.
To ensure safe operation, the generator is equipped with auxiliary components and protective devices, such as pressure regulators, pressure transmitters, water level alarms, and safety valves.
Features:
1. This boiler adopts a tube less boiler to prevent tube explosion. Due to its large water capacity, the boiler can withstand more changes. Fully automatic, easy to maintain.
2. Adopting advanced technology, energy-saving, simple operation, and fast startup.
3. Equipped with European brand burners, with functions such as flame detection, air and fuel control.
4. High quality steam with a dryness of over 96%.
5. Multiple safety protections such as pressure, temperature, and water level.
Technical Parameters:
| Product Attribute | Description |
| Trademark | TAIGUO |
| Application | Industrial |
| Size | 1420*1300*2670 |
| Structure | Water Tube |
| Pressure | Low Pressure |
| Media | Steam |
| Warranty | 1 |
| Manufacturing Level | A |
| Capacity | 0.05t/h |
| Design | Vertical |
| Maximum transport weight of boiler(t) | 0.37 |
Applications:
TAIGUO LHS Vertical Steam Boiler is a high-efficiency diesel fired steam generator
Suitable for use in factories, schools, hospitals, hotels, dry cleaners, food factories and chemical plants. The product has many functions such as washing, disinfecting, drying, cooking, ironing, gas supply and hot water supply.
Vertical Steam Boiler is carefully packaged for shipping with the following:
- Heavy duty wooden crate or box
- Foam padding
- Packing tape
- Shipping labels
- Shipping insurance
