Product Description:
The LHS type gas oil steam generator has a structure that surrounds the combustion chamber with water, which avoids heat loss and saves energy, thereby reducing operational costs. The shell and fire pipe are made of special materials and adopt European and American standard thickness, ensuring high strength, safety, stability, and reliability, as well as a long service life. Additionally, the generator offers reliable boiler auxiliaries and various safety protection devices, such as pressure controllers, pressure transmitters, water level alarms, and safety valves.
Features:
Integration of Burning Configuration System
Designing the boiler with consideration of steam generator and burner creates the best matching for the generator burning system, resulting in an organic combination for energy-saving and environment protection.
Advanced Fully Automatic Control Function
Adopting automatic micro computer program to control, the boiler is equipped with automatic pressure control, flame detection, water shortage protect, and auto alarm. Simply press the button and the system will enter an automatic running state, with all the safety protection devices starting to work, eliminating the need for on-duty personnel.
Safe and Scientific Structure Design
Equipped with a safe valve, pressure controller, water level controller, and safety interlock device, the boiler is safe and reliable to use. Fin type tubular furnace structure is used to compensate for thermal expansion, avoiding the thermal expansion and contraction stress and making the boiler structure safe and reliable, extending its service life.
Produce Good Quality Steam Quickly
The small water capacity and big steam tank design allows for quick production of steam, while the steam-water separator inside guarantees a high-quality saturated steam. A large evaporation area with good heat transfer performance and high steam quality guarantee efficient system running.
Technical Parameters:
| Property | Value |
| Media | Steam |
| Manufacturing Level | A |
| Trademark | TAIGUO |
| Application | Industrial |
| Warranty | 1 |
| Capacity | 0.05-2t/h |
| Burning Style | Chamber Combustion Boiler |
| Structure | Water Tube |
| Design | Vertical |
| Pressure | Low Pressure |
| Type | Diesel Oil Gas Fired Steam Generator, Verticle Type Gas/Oil Steam Generator |
Applications:
textile factory, food and beverage, chemical industry, medicine,light industry, rubber, printing and dyeing factory, paper factory, wood process-ing, clothing, laundry, etc.
FAQ:
1. How to buy a good boiler?
a. Choose a good supplier, A grade boiler manufacturer.
b. Specification is clear, steam or hot water, capacity,fuel,pressure and so on
c. Price is not the only problem, quality and service also important.
2. What is your main product?
Steam boiler, hot water boiler, thermal oil boiler and pressure autoclave.
Gas fired boiler, oil fired boiler, diesel fired boiler, coal fired boiler, biomass fired boiler.
Industry boiler, paper machine boiler, sugar mill boiler, printing industry boiler, food industry boiler,
power plant boiler,textile mill boiler, garment industry boiler and so on.
3. Why choose us?
a. A grade boiler factory, long history since 1976.
b. Henan boiler industrial area, Taikang No.1 boiler factory
c. China famous brand, ISO certificate
