Product introduction:
Black & Decker burner construction is based on the principle of producing thermal equipment that is extremely reliable and easily accessible to each component for machine repair, cleaning, inspection and maintenance. The special pressure resistance and the compact size and extremely low power consumption of the burner compared to its heat capacity constitute a concentrated embodiment of the technology and functions of a product with a high technical content.
Product advantage:
A. The structure of the combustion head enables the burner to obtain the best combustion ratio at each point within its operating range
B, electronic equipment control the entire operation process and safety guarantee function.
C, many models, wide capacity range.
D, easy installation and maintenance.
E, the burner assembly is complete, easy to connect on site.
Black & Decker burners are available in one stage, two poles, progressive two stages and progressive two stages with a proportional regulator (the latter implements proportional regulation operation).
Technical parameter:
| Model | TBL 85P
TBL 85P
DACA | TBL 105P
TBL 105P
DACA | TBL 130P
TBL 130P
DACA | TBL 160P
TBL 160P
DACA | TBL 210P DACA |
Thermal power most kW
Minimum kW | 850 | 1,050 | 1,300 | 1,600 | 2,100 |
| 200 | 320 | 400 | 500 | 800 |
| Operation mode | Two -stage fire |
| NOx emission mg/kWh | < 185 (Classe II EN 267) |
Motor kW
r.p.m. | 1.1 | 1.5 | 2.2 | 2.2 | 3 |
| 2,800 | 2,800 | 2,800 | 2,800 | 2,800 |
| * Consumption power kW | 1.50 | 1.90 | 2.60 | 2.60 | 3.40 |
| safety | A 400 V | 6 | 6 | 10 | 10 | 16 |
| Ignition transformer | 2 x 5 kV - 30 mA - 230 V/ 50 Hz |
| Voltage | 3N ~ 400 V ±10%- 50Hz |
| Protection level | IP 40 |
| Flame detection | Photoresistance |
| ** noise dBA | 73 | 75.5 | 79 | 79 | 87 |
| Weight kg | 82 | 88 | 92 | 92 | 95 |
| Maximum fuel viscosity (light oil) | 5.5 cst/20°C - 1.5° E / 20°C |
Flow rate most kg/h
Minimum kg/h | 71.6 | 88.5 | 109.6 | 134.9 | 177 |
| 16.9 | 27 | 33.7 | 42.2 | 67.4 |
FAQ:
Q1: How can you get the best price quickly?
1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.
Q2:Why choose us?
1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.
Q3: Details of electric control cabinet
Electric control cabinet adopts PLC touch screen, display in English. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc. In addition, the cabinet is used for set up the parameter, record and analyze the operation data, etc.
Q4:What is the using life of your boiler?
1.Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,the boiler can be used for 20-25 years.
Product Tags:
|
|
Boiler Burner Gas Heavy Oil Dual Fuel No Residue Energy Saving And Environmental Protection Images
|
