Product introduction:
Softening water equipment type:
High degree of automation; Can automatically regenerate at a fixed time and flow rate;
1. Our company's single valve, double tank, one in use and one backup softened water equipment is generally used for treating water volumes less than 10T/H.
2. Double valve and double tank softened water equipment, one for use and one for backup, is generally used in situations where the processing water volume is greater than 10T/H and continuous operation is required.
3. The double valve, double tank, one for use and one for backup softened water equipment adopts two fully automatic control valves and two resins. When the resin in one resin tank fails, another resin tank will automatically start regeneration.
Product advantage:
1. High degree of automation, stable water supply conditions, long service life, automatic, no manual intervention.
2. High efficiency, low energy consumption and economical operation cost.
3. Compact and reasonable equipment structure, easy operation and maintenance, small footprint, saving investment.
4. Easy to use, easy to install, debug and operate, stable performance of control components.
Technical parameter:
| model number | Treated
water volume T/H | Resin tank specification×quantity | Salt shaker x number | Equipment size (mm) |
| YF-0.5 | 0.5T/H | 200*1100×1 | 340*700×1 | 600*400*1200 |
| YF-1 | 1T/H | 250*1370×1 | 340*700×1 | 800*500*1500 |
| YF-2 | 2T/H | 300*1320×1 | 340*700×1 | 900*500*1500 |
| YF-3 | 3T/H | 350*1650×1 | 390*850×1 | 1000*500*1800 |
| YF-4 | 4T/H | 400*1650×1 | 500*1020×1 | 1100*700*1800 |
| YF-6 | 6T/H | 530*1750×1 | 500*1020×1 | 1300*900*2000 |
| YF-8 | 8T/H | 600*1850×1 | 580*1200×1 | 1600*1000*2100 |
| YF-10 | 10-12T/H | 750*1850×1 | 730*1310×1 | 2000*1200*2150 |
| YF-15 | 15T/H | 900*1850×1 | 875*1350×1 | 2300*1500*2400 |
| YF-20 | 18-22T/H | 1000*1850×1 | 980*1400×1 | 2500*2200*2400 |
| YF-35 | 25-35T/H | 1200*2400×1 | 1300*1310×1 | 3000*2700*3000 |
| YF-50 | 50T/H | 1500*2400×1 | 1300*1310×1 | 4000*2700*3000 |
Product display:
FAQ:
Q1: How can you get the best price quickly?
1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.
Q2:Why choose us?
1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.
Q3: Details of electric control cabinet
Electric control cabinet adopts PLC touch screen, display in English. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc. In addition, the cabinet is used for set up the parameter, record and analyze the operation data, etc.
Q4:What is the using life of your boiler?
1.Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,the boiler can be used for 20-25 years.
