DZZQ Series 720KW Small Electric Steam Generator Safe And Easy To Operate For Food Processing

Product Categories
HENAN TAIGUO BOILER PRODUCTS CO.,LTD.
Contact Now

DZZQ Series 720KW Small Electric Steam Generator Safe And Easy To Operate For Food Processing

Brand Name : taiguo boiler

Model Number : DZZQ

Certification : CE,SGS,EAC

Place of Origin : HENAN,CHINA

MOQ : 1

Price : 3200-8250USD

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 100set

Delivery Time : 20-30days

Packaging Details : nude packing

Safety Protection : Multiple

Evaporation (kg/h) : 1000

Electric heating efficiency (%) : ≥95

Voltage frequency (V/HZ) : 380/50

Dimension : 700*500*1050

Safety Features : Overpressure Protection, Water Shortage Protection, Leakage Protection

Orign : HeNan of China

Working pressure (Mpa) : 0.1-10

Rated power (kW) : 720

Application : Food Processing, Pharmaceutical Industry, Chemical Industry

Rated current (A) : 1080

Drain Way : automatic

Material : Stainless Steel

Drum Placement : Vertical Boiler

Contact Now

product presentation:

LDR series electric heating boiler is a kind of mobile steam boiler which uses tubular electric heat pipe group to directly heat water and continuously generate steam pressure. The furnace is made of boiler steel, and the electric heat pipe is connected with the furnace body by flange, which is convenient for loading and unloading, and is conducive to replacement, repair and maintenance. The furnace body and the control cabinet are separated, and all electrical components have CE and CCC demonstration marks to ensure the reliability and service life of the product, and the heating is reliable and stable (the thermal efficiency reaches 98%). With automatic water supply, water shortage, overpressure, automatic power off and alarm, leakage protection and other protection systems.

product feature:

● The boiler water volume is small, the cold furnace starts quickly, and the temperature rise and pressure increase are realized in a short time;
● Electrical components with and to ensure product safety and service life.
● Boiler operation is fully automatic control, equipped with a variety of alarm interlock protection devices to ensure efficient, safe and reliable operation of the boiler.
● The inside of the boiler can be treated with anti-corrosion, the furnace body is not easy to rust corrosion, the steam quality is high, and the boiler has a long service life.

technical specification:

Model speci fications
DZZQ-36
DZZQ-72
DZZQ-144
DZZQ-216
DZZQ-360
DZZQ-504
DZZQ-720
DZZQ-1080
DZZQ-1400
Rated power (kW)
36
72
144
216
360
504
720
1080
1400
Rated current (A)
54
108
216
324
540
756
1080
1620
2160
Voltage frequency (V/HZ)

380/50

380/50

380/50

380/50

380/50

380/50

380/50

380/50

380/50
Electric heating efficiency (%)

≥95

≥95

≥95

≥95

≥95

≥95

≥95

≥95

≥95
Number of heating tube groups (group))

2

2

4

6

10

14

20

30

40
Working pressure (Mpa)

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0
Evaporation (kg/h)

50

100

200

300

500

700

1000

1500

2000
Air outlet/
sewage outlet (DN)

25/40

25/40

25/40

25/40

40/40

50/50

50/50

65/50

65/50
Auxiliary control function
Automatic control + remote control
Product weight (kg)

85

150

318

450

750

1000

1300

2100

2600
Appearance size (m)
0.8*1.0*1.6
0.8*1.0*1.7
1.4*1.4*1.7
2.0*1.6*1.7
1.4*1.4*1.7
1.6*1.6*1.7
2.6*1.6*1.7
3.7*1.6*1.8
4.5*1.6*1.8

FAQ
Q1:How can you get the best price quickly?
1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.
Q2:Why choose us?
1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.
Q3: Details of electric control cabinet
Electric control cabinet adopts PLC touch screen, display in English. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc. In addition, the cabinet is used for set up the parameter, record and analyze the operation data, etc.
Q4:What is the using life of your boiler?
1.Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,the boiler can be used for 20-25 years.
product picture:
