300KW 500KW Electric Steam Boiler Vertical Steam Generator Energy Saving

Product Categories
HENAN TAIGUO BOILER PRODUCTS CO.,LTD.
Contact Now

300KW 500KW Electric Steam Boiler Vertical Steam Generator Energy Saving

Brand Name : TAIGUO

Model Number : DZZQ

Certification : CE、EAC、SGS

Place of Origin : Henan, China

MOQ : 1

Price : US $16000.00set

Payment Terms : L/C, T/T

Control System : PLC

Design Efficiency : 98%

Fuel : Electricity

Structural form : Vertical type

Operation Mode : Automatic

Steam yield : 0.5t/h-2t/h

Pressure : 0.1-1.0MPa

Product Name : Electric Steam Generator

Safety Protection : High Temperature, Pressure, Water Level

Size : Customizable

Steam Output : 20-1000Kg/h

Steam Temperature : 120-185℃

Voltage : 380V/50HZ

Warranty : 1 Year

Contact Now

Electric steam boiler 300kw 500KW vertical steam generator Energy saving and high thermal efficiency300KW 500KW Electric Steam Boiler Vertical Steam Generator Energy Saving300KW 500KW Electric Steam Boiler Vertical Steam Generator Energy Saving300KW 500KW Electric Steam Boiler Vertical Steam Generator Energy Saving

Model speci ficationsDZZQ-36DZZQ-72DZZQ-144DZZQ-216DZZQ-360DZZQ-504DZZQ-720DZZQ-1080DZZQ-1400
Rated power (kW)367214421636050472010801400
Rated current (A)54108216324540756108016202160
Voltage frequency (V/HZ)

380/50

380/50

380/50

380/50

380/50

380/50

380/50

380/50

380/50

Electric heating efficiency (%)

≥95

≥95

≥95

≥95

≥95

≥95

≥95

≥95

≥95

Number of heating tube groups (group))

2

2

4

6

10

14

20

30

40

Working pressure (Mpa)

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

0.1-1.0

Evaporation (kg/h)

50

100

200

300

500

700

1000

1500

2000

Air outlet/

sewage outlet (DN)

25/40

25/40

25/40

25/40

40/40

50/50

50/50

65/50

65/50

Auxiliary control functionAutomatic control + remote control
Product weight (kg)

85

150

318

450

750

1000

1300

2100

2600

Appearance size (m)0.8*1.0*1.60.8*1.0*1.71.4*1.4*1.72.0*1.6*1.71.4*1.4*1.71.6*1.6*1.72.6*1.6*1.73.7*1.6*1.84.5*1.6*1.8

300KW 500KW Electric Steam Boiler Vertical Steam Generator Energy Saving300KW 500KW Electric Steam Boiler Vertical Steam Generator Energy Saving
