Product Description:
Our Concrete Autoclave is designed for producing Aerated Concrete (AAC) Block with Customized Size, High Pressure and High Temperature. It is fully automatic in operation and is an indispensable piece of equipment in the production process of AAC blocks. Our Concrete Autoclave is designed with the highest quality components and features the latest technology to ensure maximum efficiency and reliability. With its superior performance, it is widely used for production of AAC blocks.
Our Concrete Autoclave has a large capacity and can be customized according to customer's needs. It features a stainless steel chamber and a high-pressure steam system that can reach up to 20 bar, making it suitable for high temperature and high pressure applications. The advanced control system provides precise temperature and pressure control for efficient and safe operation. The automated system also ensures consistent and accurate product quality.
Our Concrete Autoclave is designed to be safe and easy to use. It is equipped with safety features such as pressure relief valves and emergency shut-off valves to ensure the safety of personnel and equipment. The operation is also simple and intuitive, making it easy for operators to use.
Our Concrete Autoclave is the perfect solution for producing high quality AAC blocks with precision and efficiency. It is the ideal choice for those looking to achieve the highest quality results in Autoclave for AAC Block production.
Features:
1.Autoclavedoor seal uses professional manufacturers of imported rubber sealing ring, easy installation, good sealing, long service life.
2.Autoclave body bearing aimed at different position, Settings are fixed supprort, activities bearing, special bearings at the end of the three forms. Better meet the kettle body heat bilges cold shrink, guarantee the autoclaved autoclave normal work and service life.
Technical Parameters:
| Specification(m) | Φ1.65×21 | Φ2×21 | Φ2.5×24 | Φ2.85×26 | Φ3×23 | | Rated Pressure(MPa) | 1.1/1.4 | 1.4 | 1.4/1.6 | 1.6 | 1.6 | | Design Temp(ºC) | 187/195 | 195 | 195/204 | 204 | 204 | | Maximum Operating Pressure(MPa) | 1.0/1.3 | 1.3 | 1.3/1.5 | 1.5 | 1.5 | | Autoclave Inside track gauge (mm) | 600 | 600 | 800 | 600 | 915 | | Volume(m³) | 46 | 68 | 121 | 172 | 172 | | Weight(t) | 18.7/21.5 | 25 | 51/58 | 62 | 70 | | Dimension (m) | Length | 21.7 | 22.4 | 25.56 | 27.63 | 24.95 | | Width | 2.62 | 3.05 | 3.25 | 3.58 | 3.65 | | Height | 2.6 | 3.3 | 4 | 4.49 | 4.85 | | |
Applications:
Applications: Suitable for anti-corrosion, mold proof, moth proof, termite proof,flame retardant, dyeing and other processing of various types of wood.
Support and Services:
We provide technical support and service for our Concrete Autoclave products, including:
- Professional guidance for installation and commissioning
- Providing technical training and customer service
- Providing regular maintenance and repair services
- Providing on-site technical support and services
- Providing spare parts and accessories
FAQ:
1. How to buy a good boiler?
a. Choose a good supplier, A grade boiler manufacturer.
b. Specification is clear, steam or hot water, capacity,fuel,pressure and so on
c. Price is not the only problem, quality and service also important.
2. What is your main product?
Steam boiler, hot water boiler, thermal oil boiler and pressure autoclave.
Gas fired boiler, oil fired boiler, diesel fired boiler, coal fired boiler, biomass fired boiler.
Industry boiler, paper machine boiler, sugar mill boiler, printing industry boiler, food industry boiler,
power plant boiler,textile mill boiler, garment industry boiler and so on.
3. Why choose us?
a. A grade boiler factory, long history since 1976.
b. Henan boiler industrial area, Taikang No.1 boiler factory
c. China famous brand, ISO certificate
