Programmable Concrete Autoclave Aac High Efficiency

Name: Programmable Concrete Autoclave Aac High Efficiency
Brand: TAIGUO
Price: 5000 USD

Programmable Concrete Autoclave Aac High Efficiency Manufactures

Brand Name : TAIGUO

Model Number : DN

Certification : SGS EAC CE

Place of Origin : Zhoukou

MOQ : 1

Price : US5000-69500 set

Payment Terms : D/A, D/P, T/T

Supply Ability : 10set

Delivery Time : 20-25 days

Packaging Details : Whole box packaging

Controls : Programmable

Method : Autoclaved Aerated Concrete

Dimension(L*W*H) : customized

Noise Level : Low

Product Name : Aac Autoclave

Automatic : yes

Size : 1.45-50M Length according to client's requirement

Warranty : 1 Year

Weight (KG) : 36000 kg

Condition : New

Core Components : PLC, Pressure vessel, Engine, Gear, Motor, Bearing, Gearbox

Contact Now

Autoclave belongs to pressure vessel which has explosion risk. According to the supervision regulation on safety technology for pressure vessel on divide standard of pressure vessel, the product is part of first and second class pressure vessel.

This product is key equipment which has a widely application in building material factory to autoclaved cure different kinds of building materials. It is also used in areas of chemical, textile, wood, metallurgy, military industry. Convenient operation, security and reliable are its advantages .

Programmable Concrete Autoclave Aac High Efficiency

Autoclave Model Specifictation Details
Name	Unit	Specification & Parameter
Diameter Φ	mm	1650	2000	2050	2550	2680
Effective length	mm	25500-27500	31000-36000	2650	31000-39000	31000-39000
Working pressure	MPa	1.3-1.4	1.3-1.4	1.3-1.4	1.3-1.4	1.3-1.4
Design pressure	MPa	1.5-1.6	1.5-1.6	1.5-1.6	1.5-1.6	1.5-1.6
Working temperature	℃	195	195	201	201	201
Design temperature	℃	198	198	204	204	204
Working medium	saturated steam
Inner rails distance	mm	600-800	600-800	600-800	600-800	600-800
Capacity	m3	54.5-58.5	97-113	87	152-191	172-205
Total weight	kg	22000-26000	38330-39500	35120	58500-70115	60500-79000
Dimension	customized
All the LENGTH/DIAMETER/RAIL INNER DISTANCE/DOOR OPENING can be CUSTOMIZED, according to client'srequest.
