Brick Block Making Autoclave Aac Machine Low Noise

Product Categories
HENAN TAIGUO BOILER PRODUCTS CO.,LTD.
Contact Now

Brick Block Making Autoclave Aac Machine Low Noise

  • 1
  • 2

Brand Name : TAIGUO

Model Number : DN

Certification : SGS EAC CE

Place of Origin : Zhoukou

MOQ : 1

Price : US5000-69500 set

Payment Terms : D/A, D/P, T/T

Supply Ability : 10set

Delivery Time : 20-25 days

Packaging Details : Whole box packaging

Method : Autoclaved Aerated Concrete

Dimension(L*W*H) : customized

Noise Level : Low

Product Name : Concrete Autoclave

Automatic : yes

Size : Customized

Warranty : 1 Year

Weight (KG) : 36000 kg

Condition : New

Core Components : PLC, Pressure vessel, Engine, Gear, Motor, Bearing, Gearbox

Capacity : Large Capacity

Control System : Computer Control

Cooling Method : Water Cooling

Heating Method : Electric Heating

Material : Steel

Power : 20KW

Pressure : High Pressure

Pressure Gauge : Digital Pressure Gauge

Safety Device : Safety Valve

Temperature Range : High Temperature

Voltage : 220V/380V

Contact Now

Autoclave belongs to pressure vessel which has explosion risk. According to the supervision regulation on safety technology for pressure vessel on divide standard of pressure vessel, the product is part of first and second class pressure vessel.
This product is key equipment which has a widely application in building material factory to autoclaved cure different kinds of building materials. It is also used in areas of chemical, textile, wood, metallurgy, military industry. Convenient operation, security and reliable are its advantages .
Brick Block Making Autoclave Aac Machine Low Noise
Main Feature
1. Thermal Insulationlt has highest thermal rating in the industry-.R30! Thus provides well insulated interiors, keepingout warm air in summer and cold air in winters.AAC reduces Air conditioning cost by 30%.
2.Sound proofAAC wall has an excellent sound Transmission class (STC) ,rating of 44. Result: Virtually Soundproof Interiors!
3. Earthquake Resistant
Earthquake forces on structure are proportional to the weight of the building, hence AAC showsexcellent resistant to earthauake forces. Regions of high seismic activity like Japan exclusivelyuse AAC. lt has been proven to withstand wind loads of category 5 tropical storms.
4. Floor Space Area
Use of thinner blocks (6" instead of 9" exterior walls) because of its excellent water barrier &insulation properties leads to an increase in floor space area between 3-5%
5.Cost saving
Being lightweight AAC drastically reduces the dead weight of building, resulting into reduction insteel (up to 27%) and cement (up to 20%) structural cost saving.Being 8 times the size of a claybrick, AAC wall construction involves 1/3 the joints, thus an overall mortar saving up to 66%.lts automatic manufacturing process gives AAC an exceptional dimensional accuracy & smoothsurfaces, eliminating need of three-coat plaster walls and allows for a final 6 mm skim coat (put-ty/POP).
6.Fire Resistant
Best in class fire rating of 4 hours. The melting point of AAC is over 1600 c, more than twice thetypical temperature in a building fire of 650 c.
Autoclave Model Specifictation Details
Name Unit Specification & Parameter
Diameter Φ mm 1650 2000 2050 2550 2680
Effective length mm 25500-27500 31000-36000 2650 31000-39000 31000-39000
Working pressure MPa 1.3-1.4 1.3-1.4 1.3-1.4 1.3-1.4 1.3-1.4
Design pressure MPa 1.5-1.6 1.5-1.6 1.5-1.6 1.5-1.6 1.5-1.6
Working temperature ℃ 195 195 201 201 201
Design temperature ℃ 198 198 204 204 204
Working medium saturated steam
Inner rails distance mm 600-800 600-800 600-800 600-800 600-800
Capacity m3 54.5-58.5 97-113 87 152-191 172-205
Total weight kg 22000-26000 38330-39500 35120 58500-70115 60500-79000
Dimension customized
All the LENGTH/DIAMETER/RAIL INNER DISTANCE/DOOR OPENING can be CUSTOMIZED, according to client'srequest.
Brick Block Making Autoclave Aac Machine Low Noise
Brick Block Making Autoclave Aac Machine Low Noise
