98% Yyqw Series Industrial Hot Oil Heater Gas Diesel Oil Fired ODM

  • 1
  • 2

Brand Name : TAIGUO

Model Number : YYQW

Certification : CE\EAC\SGS\ISO19001

Place of Origin : HENAN

MOQ : 1

Price : USD9000-22500 set

Payment Terms : D/P, T/T, L/C, D/A

Supply Ability : 10set

Delivery Time : 15-25DAYS

Packaging Details : Whole box packaging

Burner : Optional

Capacity : Customized

Control System : Automatic Control

Design : Compact Design

Fuel Type : Oil

Function : Thermal Oil Boiler

Installation : Easy Installation

Pressure : Low Pressure

Service : OEM, ODM,

Structure : Water Tube

Thermal Efficiency : >98%

Usage : Industrial

Warranty : 1 Year

Contact Now

98% Yyqw Series Industrial Hot Oil Heater Gas Diesel Oil Fired ODM98% Yyqw Series Industrial Hot Oil Heater Gas Diesel Oil Fired ODM98% Yyqw Series Industrial Hot Oil Heater Gas Diesel Oil Fired ODM

  1. Thermal oil heater is a kind of special industrial furnace which uses diesel oil as the fuel, the furnace takes heat carrier oil as medium and uses the hot oil circulating pump force the medium to make liquid circulation; then the thermal energy will be transmitted to the devices and back to the furnace to be reheated.
    This series boiler have advanced program control system, equipped with liquid level controller , pressure controller, temperature controller, and alarms to make sure the boiler work orderly and safe. So it is a kind of safe boiler with high efficiency and low power consumption.

98% Yyqw Series Industrial Hot Oil Heater Gas Diesel Oil Fired ODMmodel

ltem

YY(Q)W

350

YY(Q)W

500

YY(Q)W

700

YY(Q)W

1400

YY(Q)W

2100

YY(Q)W

2800

YY(Q)W

3500

YY(Q)W

4200

YY(Q)W

7000

YY(Q)W

14000

Rated thermal p

ower

 KW 350 500 700 1400 2100 2800 3500 4200 7000 14000
Design pressure Mpa 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1
Medium outlet t emperature C ≤350 ≤350 ≤350 ≤350 ≤350 ≤350 ≤350 ≤350 ≤350 ≤350
Heating area m 21.3 24 40 78.5 94.5 157 205.2 240 410 98% Yyqw Series Industrial Hot Oil Heater Gas Diesel Oil Fired ODM710
Fuel light oil/heavy/LNG/CG

Fuel

 Light oil

Kg/h

 37 52 69 140 210 280 350 420 680 1360
LNG

Nm3/h

 44 63 83 170 260 332 425 498 810 1620
Thermal efficiency 96% 96% 96% 96% 96% 96% 96% 96% 96% 96%
Furnace oil cont ent m3 0.25 0.3 0.5 1.1 1.7 2.29 3.8 4.3 7 15.5

Boiler dimension

s

mm

2100×

1390×

2055

2200×

1390×

2055

3240×

1470×

2260

4145×

1900×

2786

5020×

2050×

3080

5526×

2326×

3230

6555×

2470×

3634

6753×

2838×

3704

8200×

3050×

3800

12000×

3780×

4350
Boiler transport weight

T

2.58

3

3.7

6.9

8.8

11.5

17.8

19.8

27.5

42
Oil inlet

DN

 80 100 100 125 150 150 200 200 250 350
Oil outlet

DN

 80 100 100 125 150 150 200 200 250 350
Expansion tank

m3

 1.5 1.5 1.5 2.5 2.5 3 3 4.5 6 8
Storage tank

m3

 2.5 2.5 2.5 5 5 8 8 10 15 25
ChimneyΦ mm 280 280 280 350 400 400 500 500 700 1000

98% Yyqw Series Industrial Hot Oil Heater Gas Diesel Oil Fired ODM
