300kg 500kg Chain Grate Biomass Steam Boiler Small Scale For Dyeing

Product Categories

Gas Oil Boiler [138]
Industrial Hot Water Boiler [73]
Thermal Oil Boiler [89]
Coal Fired Boiler Operation Manual [51]
Chain Grate Biomass Steam Boiler [61]
Electric Steam Boiler [53]
Concrete Autoclave [56]
Vertical Steam Boiler [97]
Coal Fired Water Tube Boiler [32]
Electric Steam Generator [55]
Impregnation Autoclave [53]
Water Tube Steam Boiler [78]
Hot Air Furnace [29]
Glass Lined Reactor [10]
Boiler Auxiliaries [16]

HENAN TAIGUO BOILER PRODUCTS CO.,LTD.

Contact Now

300kg 500kg Chain Grate Biomass Steam Boiler Small Scale For Dyeing

Name: 300kg 500kg Chain Grate Biomass Steam Boiler Small Scale For Dyeing
Brand: TAIGUO
Price: 10000.00 USD

300kg 500kg Chain Grate Biomass Steam Boiler Small Scale For Dyeing Manufactures

Brand Name : TAIGUO

Model Number : DZL

Certification : CE、EAC、SGS

Place of Origin : Henan, China

MOQ : 1

Price : USD$10000.00

Payment Terms : L/C, T/T, D/P

Supply Ability : 10set

Delivery Time : 25 working days

Packaging Details : Bulk, packaged

Product type : Industrial steam

Industrial steam : 1t/h-10t/h

Working pressure : 1.0、1.25、1.6Mpa

Fuel : Biomass, Wood, Coal

Rated feed water temperature : 20℃

Warranty : 1 Year

Condition : New

Weight : Refer to the models

Boiler Structure : Firetube

Contact Now

Product introduction:

The DZL boiler is a single barrel vertical water pipe shell steam boiler. The combustion equipment is a chain stove. The left and right sides of the stove are equipped with a fins of water cooling walls. The heating surface is arranged in the pot drum.
The chain furnace rows of mechanical coal inlet, equipped with a blossom and induced fan to achieve mechanical ventilation, and equipped with scratch furnace slag machines to achieve mechanical furnaces.

Technical parameter:

Mode l item		DZL1	DZL2	DZL3	DZL4	DZL6	DZL8	DZL10	DZL12	DZL15
Rated evaporation capacity(t/h)		1	2	3	4	6	8	10	12	15
Rated pressure(Mpa )		0 .7/ 1 .0/ 1 .25	0 .7/ 1 .0/ 1 .25	0 .7/ 1 .0/ 1 .25	1 .25/ 1 .6	1 .25/ 1 .6	1 .25/ 1 .6	1 .25/ 1 .6	1 .25/ 1 .6	1 .25/ 1 .6
Rated steam temperat ure( ℃ )		170/ 184/ 194	170/ 184/ 194	170/ 184 / 194	194/204	194/204	194/204	190/204	194/204	194/204
Feed water temperat ure( ℃ )		20	20	20	20	20	20	20	20	20
Heating Area( m)	Body	~33	~50	~75	~100	~170	~200	~250	~340	~415
Heating Area( m)	Economizer	20 .7	25 .3	28 .6	33 . 12	87 .2	98	145	168	189
Effective area of garte ( m)		2 .22	4 . 1	5 .85	6.2	7 .95	9 .75	10 .77	13 .4	16 .6
Fuel type		Biomass pellet,wood sawdust,bamboo chip,wood block,straw ,Jute, palm shell
Fuel Consumption (kg/h)		~200	~400	~600	~800	~1000	~1200	~1400	~1600	~1800
Flue gas temperat ure( ℃ )		~150	~150	~150	~150	~150	~150	~150	~150	~150
T hemal efficiency(%)		~82	~82	~82	~82	~82	~82	~82	~82	~82
Weight of biggest part for t ransportation(t)		17	18 .5	20	25	35	45	58	64	77
Overall dimension of biggest part for t ransportation( m)		5 . 12 .2 3	5 .52 .3 3 .3	6 .42 . 43 .5	6 .62 .6 3 .6	8 . 12 .9 3 .8	8 .33 . 1 4 .0	8 .63 .2 4 .2	9 .84 .2 4 .5	12 .94 7 .5

Work flow chart:

300kg 500kg Chain Grate Biomass Steam Boiler Small Scale For Dyeing

After-sales service:

1. Our service tenet is "to provide customers with sincere, quality service". We are committed to honesty and good service to our customers and are committed to continuously improving the quality of service and increasing user satisfaction.
2. Provide technical advice to users, including the use and maintenance of products
Assembly, use characteristics and other technical problems, where the user needs to provide services,
The company will send the best engineering and technical personnel for customer service and technical consultation.
3. When users use our products for quality problems, they will reply within 1 hour when receiving customer service needs, and provide solutions within 24 hours.
4. Implement the "Product quality responsible person system". After the contract is signed, from product manufacturing, warehousing, delivery to installation, trial operation, the whole process of service, improve the quality of the project.
300kg 500kg Chain Grate Biomass Steam Boiler Small Scale For Dyeing
