Horizontal 50 Ton Coal Fired Water Tube Steam Boiler For Fertilizer Plant

Brand Name : TAIGUO

Model Number : SZL

Certification : SGS EAC CE

Place of Origin : HENAN

MOQ : 1

Price : USD11000-32500 set

Payment Terms : L/C, D/A, D/P, T/T

Delivery Time : 15-25DAYS

After-Sales Service : Engineers Available to Service Machinery Overseas

Boiler Type : SZL coal biomass steam boiler

Burner : Optional

Control System : PLC

Design Efficiency : ≥81%

Feed Water Temperature : 20-105℃

Fuel : Coal, biomass, wood chips, rice husk, palm shell, etc.

Installation : Under Technical Guidance

Origin : China

Rated Steam Capacity : 2-20t/h

Rated Steam Temperature : 184-450℃

Rated Working Pressure : 1.25-2.5Mpa

Transport Package : Export Standard Package

Warranty : 12 Months

Contact Now

Horizontal Chain Grate 50 Ton Coal-Fired Water Tube Steam Boiler for Fertilizer PlantHorizontal 50 Ton Coal Fired Water Tube Steam Boiler For Fertilizer PlantHorizontal 50 Ton Coal Fired Water Tube Steam Boiler For Fertilizer PlantHorizontal 50 Ton Coal Fired Water Tube Steam Boiler For Fertilizer Plant

Model

item

SZL6

SZL8

SZL10

SZL15

SZL20

SZL25

SZL30

SZL35
Rated evaporation capacity(t/h) 6 8 10 15 20 25 30 35
Rated pressure( Mpa) 1.25/1.6/2.5 1.25/1.6/2.5 1.25/1.6/2.5 1.25/1.6/2.5 1.25/1.6/2.5 1.25/1.6/2.5 1.25/1.6/2.5 1.25/1.6/2.5
Rated steam tmperature(℃) 194/204/226 194/204/226 194/204/226 194/204/226 194/204/226 194/204/226 194/204/226 194/204/226
Feed water temperature (℃) 20 20 20 20 20 20 20 20

Heating

Area(㎡)

 Body ~142 ~215 ~234 ~318.5 ~504 ~646 ~738 ~852.3
Economizer 130 130 174 348.8 377.6 500.6 551 685.8
Effective area of garte (㎡) 7.52 10.25 11.8 18 23.2 29.8 35 41.2
Fuel type Coal, Biomass pellet, jute, Palm kernel shell
Fuel Consumption(kg/h) ~880 ~1160 ~1450 ~2200 ~2900 ~3650 ~4350 ~5100

Exhaust flue gas

temperature(℃)

 ~165 ~165 ~165 ~165 ~165 ~165 ~165 ~165
Themal efficiency(%) ~80 ~80 ~80 ~80 ~80 ~80 ~80 ~80

Weight of biggest

part fotransportation (t)

22.5

25

28

30

35

40

45

50

Overlall dimension part for transportation

L*W*H(mm)

up:6150*2840*3540

Down:7275*2852*2580

Up:6971*2933*3540

Down:8056*2945*2580

Up:7855*3240*3540

Down:9025*3200*2580

Up:10000*3240*3540

Down:12000*3200*3080

Up:11000*3240*3540

Down:14000*3200*3080

Up:12000*3240*3540

Down:16000*3200*3080

Up:13000*3240*3540
down:18000*3200*3080

Up:14000*3240*3540

Down:20000*3200*3080

Horizontal 50 Ton Coal Fired Water Tube Steam Boiler For Fertilizer PlantHorizontal 50 Ton Coal Fired Water Tube Steam Boiler For Fertilizer Plant
