Product Description:

Thermal oil heater is a kind of special industrial furnace which uses diesel oil as the fuel, the furnace takes heat carrier oil as medium and uses the hot oil circulating pump force the medium to make liquid circulation; then the thermal energy will be transmitted to the devices and back to the furnace to be reheated.

This series boiler have advanced program control system, equipped with liquid level controller , pressure controller, temperature controller, and alarms to make sure the boiler work orderly and safe. So it is a kind of safe boiler with high efficiency and low power consumption.

Technical Parameters:

1.Optimum three-coil design

The boiler with large heating area has high efficiency.

The third pipe protects the boiler shell from deformation.

2.External oil collection box

Protect the high temperature flue gas in the heating chimney.

Easy maintenance.

3.Automatic control measures are perfect

Precise oil temperature control, temperature, pressure and smoke temperature multiple control protection

Safe and reliable operation.

model ltem YY(Q)W 350 YY(Q)W 500 YY(Q)W 700 YY(Q)W 1400 YY(Q)W 2100 YY(Q)W 2800 YY(Q)W 3500 YY(Q)W 4200 YY(Q)W 7000 YY(Q)W 14000 Rated thermal p ower KW 350 500 700 1400 2100 2800 3500 4200 7000 14000 Design pressure Mpa 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 Medium outlet t emperature C ≤350 ≤350 ≤350 ≤350 ≤350 ≤350 ≤350 ≤350 ≤350 ≤350 Heating area m 21.3 24 40 78.5 94.5 157 205.2 240 410 710 Fuel light oil/heavy/LNG/CG Fuel Light oil Kg/h 37 52 69 140 210 280 350 420 680 1360 LNG Nm3/h 44 63 83 170 260 332 425 498 810 1620 Thermal efficiency 96% 96% 96% 96% 96% 96% 96% 96% 96% 96% Furnace oil cont ent m3 0.25 0.3 0.5 1.1 1.7 2.29 3.8 4.3 7 15.5 Boiler dimension s mm 2100× 1390× 2055 2200× 1390× 2055 3240× 1470× 2260 4145× 1900× 2786 5020× 2050× 3080 5526× 2326× 3230 6555× 2470× 3634 6753× 2838× 3704 8200× 3050× 3800 12000× 3780× 4350 Boiler transport weight T 2.58 3 3.7 6.9 8.8 11.5 17.8 19.8 27.5 42 Oil inlet DN 80 100 100 125 150 150 200 200 250 350 Oil outlet DN 80 100 100 125 150 150 200 200 250 350 Expansion tank m3 1.5 1.5 1.5 2.5 2.5 3 3 4.5 6 8 Storage tank m3 2.5 2.5 2.5 5 5 8 8 10 15 25 ChimneyΦ mm 280 280 280 350 400 400 500 500 700 1000

Packing and Shipping:

Pre-sale service:
1.We help customer choose the best boiler model according to different requirements of various industry.

2.Before delivery we will provide foundation drawing, layout drawing, boiler room layout, etc.
In-sale service:
1.We keep 24 hours online and keep close contacts during the production process to ensure on time delivery with perfect finished product.
After-sale service:
1.provide full range of original spare parts.
2.Engineers abroad installation and commissioning service is available.
