Industrial Vacuum Hot Water Boilers Have Low Operating Costs And High Thermal Efficiency

  • 1
  • 2
  • 3

Brand Name : TAIGUO

Model Number : ZKS

Certification : CE、EAC、SGS

Place of Origin : Henan, China

MOQ : 1

Price : US $5000.00-10000.00

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100set

Delivery Time : 10-30working days

Packaging Details : Bulk, packaged

Product name : Vacuum hot water boiler

use : Heating, domestic hot water supply

Industry of use : Schools, hotels, bath centers, office buildings, etc

Rated power : 0.35-42MW

Contact Now

Product introduction:

The vacuum hot water boiler adopts the flue gas three-return method, and adopts the wet back vacuum hot water boiler, the boiler shell adopts the round furnace body and the square gas chamber method, the flue gas pipeline layout is reasonable, the combustion is full, the flue gas flow is smooth, the exhaust temperature is reduced, and the efficiency of the whole machine is improved. The high-temperature flue gas produced by combustion, after a total of three returns of one furnace return and two smoke pipe return, the temperature is greatly reduced, and the hot medium water surrounds the furnace and the periphery of the smoke pipe, and the heat transfer effect of the furnace and the smoke pipe is good.

advantage:

The leak detection device of our company's unique high-efficiency three-pass wet back vacuum hot water boiler and the corresponding leak detection process improve the accuracy and reliability of leak detection, and ensure the stability of low evaporation point during the operation of high-efficiency vacuum hot water boiler; The multi-parameter integrated control system is developed by using single chip microcomputer control technology, which ensures the effective operation of vacuum hot water boiler under the best condition.
The control goal of the system is to ensure that the effluent temperature meets the requirements of the load. The control object of the system is the inlet air volume and the inlet fuel volume of the burner. The system collects the effluent temperature and the temperature signal of the heat medium water, and sets the expected value at the same time. By PID algorithm, the system can adjust the inlet air volume and the inlet fuel volume of the burner in real time.

Technical parameter:

Industrial Vacuum Hot Water Boilers Have Low Operating Costs And High Thermal Efficiency Model

item

ZKS0.35 ZKS0.5 ZKS0.7 ZKS1.05 ZKS1.4 ZKS1.75 ZKS2.1 ZKS2.8 ZKS3.5 ZKS4.2
-85/60-Q
Rated power (MW) 0.35 0.5 0.7 1.05 1.4 1.75 2.1 2.8 3.5 4.2
Rated working pressure (Mpa) -0.02
Heat exchanger (Mpa) ≤2.5
Rated outlet water temperature (℃) 85
Rated return water temperature (℃) 60
Thermal efficiency (%) ≥98
Water capacity (L) 1340 2000 2600 3250 3950 4920 5950 7430 8520 9560
Water inlet and outlet (DN) 50 65 80 100 125 150 200
Pollution discharge (DN) 40 50

Fuel consumption

Light oil

(Kg/h)

32.4 43.2 64.7 97.1 129.5 162 194.2 259 324 389

Natural

(Nm³/h)

36.8 49 73.5 110.3 147 183.6 220.6 294.1 368 441.2

City gas

(Nm³/h)

83.4 111.1 166.7 250 333.3 416.7 500 666.7 833 1000

Outline dimension

Length

(mm)

3050 3300 3550 4100 4200 4500 4600 5100 5500 6100

Width

(mm)

1400 1400 1500 1600 1700 1800 2000 2150 2450 2400

Height

(mm)

1800 1800 1850 2000 2100 2200 2450 2650 2820 2820
weight (kg) 2400 2550 3350 4600 5950 6700 7900 10500 14000 15500
